KEY FEATURES AND BENEFITS
• 10.1-Inch Multi-Point Interactive Panel
-Multi-Point touch capability screen to easily book rooms or check in/ out at the RoomPanel Plus.
•Face Recognition Camera *
-Enhanced face recognition security and check-in function.
•High Visibility LED Bars out Room Status
-Full RGB LED bars for immediate all-round visible communication of room status.
•Ambient Light & Proximity Sensor Embedded
-Environment self-adaptation. Automatically adjust the screen brightness and automatically wake up the screen.
•Various Mounting Methods
-Supporting accessories such as no inclination or 20-degree inclination, mullion hangers, 3M glue, etc. •Orientation Optional
-Easy to mount with portrait or landscape.
•PoE or DC Power
-Minimalist and flexible installation, keep workspace tidy and modern.
•Remote Device Management
-Easily monitor, manage, and diagnose by Yealink Management Cloud Server
•WiFi&BLE5.2
-Support using the wireless protocol to connect the front-end network and RoomSensor.
•RFID & NFC Embedded *
-Enhance ID authorization security and track meeting attendees.
•Actions with Occupancy Sensor
-Actions with the room occupancy sensor, such as automatic release, automatic check-in, etc.
•Extensive APP compatibility
-Support the integration of third-party APP applications.
BASIC
• Operating System: Android 11
• Power Supply:
- Power over Ethernet (IEEE 802.3af/at)
- DC 12V /1.25A
DISPLAY
• Size(in): 10.1″ LCD Panel
• Resolution: 1280x800
• Touch Screen: 10 points capacitive multitouch
• Contrast: 1000:1
• Viewing Angle: ±90°
• Anti-Fingerprints: Anti-fingerprint Coating
SENSORS
• Ambient Light Sensor
• TOF Proximity Sensor
CAMERA
• Pixel: 2 million pixels
CONNECTIVITY
• 1 x Fast ethernet port(10/100Mbps)
• Wi-Fi: 802.11a/b/g/n/ac
• Bluetooth: 5.2
• RFID/NFC: 13.56MHz
• USB: 1 x USB-A port
• Button: 1 x Reset pin hole
AUDIO
• Microphone: 2 x Microphone
• Speaker: 2 x Speaker
MOUNTING
• Angle: No inclination or 20-degree inclination
• Method: Wall, glass or side mount
- 0° Mount Bracket
- 20° Mount Bracket
- Mullion Mount Bracket
ENVIRONMENTAL
• Operating Temperature: 0-40℃
• Operating Humidity: 10-95%, non-condensing
DIMENSIONS
• Weight(g/lb): 627 /1.38
• Size(mm/in): 247.6×166.4×26.5/9.75″ ×6.55″ ×1.04″
