ALL-IN-ONE DESIGN:
- Multi-Touch 55”/75″ Display
- Native Zoom Rooms Meeting Software
- Native Microsoft Teams Meeting Software (Android Edition)
- 4K Camera
- 15-Microphone Array
- Integrated Speaker System
- Wall Mount Included
BRING YOUR OWN DEVICE (BYOD)
- Smart Connect via single charging USB-C Cable (included) or HDMI In + USB
- Extension of display via DP (computer must support USB-C Alt-mode DisplayPort)
- Touchback feature for Windows and Mac OS
- Use D7X Camera, Microphone, Touch and Speakers with any Software Client
- HDMI Ingest for monitor and content sharing modes
Laptop charging (up to 65W)
SHARING:
- Zoom Rooms:
- Wireless in meeting sharing
- Wireless Apple screen mirroring (Airplay)
- Wireless proximity sharing
- Wired USB-C content sharing with touch back capabilities (Windows and MacOS)
- Wired HDMI capture card
MULTI-TOUCH DISPLAY:
- LED 55” / 75″
- Ultra HD 4K / 16:9
- 20 touch-points
- Low latency- 50 ms response time
- 180 touch-point reporting rate
- AI based to improve the touch accuracy
- Supports dual screens with extended screen support available
4K CAMERA SYSTEM:
- D7X 55″: Field of View (FOV) 120°
- D7X 75″: Field of View (FoV) 90°
- Vertical FOV 88°
- PTZ and preset
- Zoom Rooms Auto framing
- Zoom Rooms Smart Gallery
- DTEN Smart Framing
AUDIO SYSTEM:
-15-Microphone Array
-Integrated Stereo Speakers
-Acoustic Echo Cancellation
-Automatic Gain Control (AGC)
-Automatic Noise Reduction
INPUTS & OUTPUTS:
D7X Windows Edition:
-PC Module
-HDMI out x 1 (CEC, HDCP2.2)
-USB 3.1 x 4
-3.5-mm Jack x 1 (Mic + Headphone)
-Ethernet 1 GigE (RJ45) x 1
-On D7X Module:
-HDMI In x 1 (CEC, HDCP1.4, Dolby AC3)
-USB-C: USB3.1 Data + DP1.4 + 65W charging
D7X Android Edition:
-OPS Module
-USB-A 3.0 x 2
-USB-C x 2 (USB 3.0 Data +DP 1.4 + 65W charging)
-3.5 mm Audio Jack x 2 (Mic + Headphone)
-HDMI In x 1 (CEC, HDCP2.2, Dolby AC3)
-HDMI Out x 1 (CEC)
-Ethernet 1 GigE (RJ45) x 1
NETWORK:
-Ethernet (RJ-45) 1 GigE
-Wi-Fi 802.11a/b/g/n/ax (Support WiFi i6)
-IPv4 Dynamic Host Configuration Protocol (DHCP)/ Static
-HTTP/HTTPS Proxy Support
-Bluetooth 5.2
VESA:
-D7X 55″ VESA Pattern:
400 x 300 mm
-D7X 75″ VESA Pattern:
800 x 400 mm
POWER:
-100 to 240 V AC, 50 to 60 Hz
PRODUCT DIMENSIONS:
DTEN D7X 55″:
49 x 30.5 x 2.13 in (1245 x 774 x 54 mm)
DTEN D7X 75″:
66.1 x 39.5 x 2.18 in (1679 x 1004 x 55.4 mm)
PRODUCT WEIGHT:
DTEN D7X 55″:
47 lbs (21.3 kg)
DTEN D7X 75″:
79.6 lbs (36.1 kg)
OPERATING TEMPERATURE AND HUMIDITY:
- Operating Temperature 0°C to 40°C
- Storage Temperature -10°C to 60°C
- Operating Humidity 20% to 80% RH
- Storage Humidity 10% to 60% RH
IN THE BOX:
- DTEN D7X x1
- Wall Mount x1
- Stylus x1
- Power cord x 5 (Type B,D,F,G,I)
- USB-C cable x 1 (For BYOD)
- Antenna x 2
- Product Guide
